AS05804PS-X-R

Description
  • Venting in the magnetic motor creates forced-air cooling limiting power compression
  • Two-layer copper-clad aluminum wire for great transient response
  • Water and dustproof to IP65
  • Designed for use with two APR050SO-R for improved bass response
Dimensions
  • Units: mm
  • Length: 55.30
  • Width: 58.30
  • Height: 33.80
  • Shape: Square
Features
  • Poly-coated paper cone for warm natural sound and improved ruggedness
Electrical Specifications
  • Device Type Speaker
  • Technology Electro-Mechanical
  • Mount Type Flange
  • Rated Input Power 10 W
  • Resonant Frequency 140 Hz
  • SPL at 10cm 98 dB
  • Impedance 4 Ohm
  • Frequency Range Min 140.00 Hz
  • Frequency Range Max 20000.00 Hz
