DMM-4026-B-R

Description
  • Digital MEMS microphone with PDM output
  • Super-wide 20 Hz to 18,000 Hz frequency response
  • Virtually 0 current draw when in Sleep Mode
Dimensions
  • Units: mm
  • Length: 4.00
  • Width: 3.00
  • Height: 1.00
Features
  • Low Power and Full Power Modes for preserving battery life when needed
Electrical Specifications
  • Device Type Microphone
  • Technology MEMS
  • Mount Type Surface Mount
  • Package Size 4 x 3 x 1 mm
  • Directivity Omni-Directional
  • Rated Voltage 1.8 Vdc
  • Sensitivity -26 ± 1 dB
