AS09208AR-R

Description
  • Great bass response with up to 4mm of usable Xmax
  • 1 liter Vas, 0.743 Qts, and 93 Hz Fs for use in a wide range of enclosures
  • Great 10W continuous, 15W max power handling for up to 94 dB output at 1 meter
Dimensions
  • Units: mm
  • Length: 92.00
  • Width: 92.00
  • Height: 49.60
  • Shape: Round
Features
  • Black anodized aluminum cone and dustcap for a sleek, modern look
Electrical Specifications
  • Device Type Speaker
  • Technology Electro-Mechanical
  • Mount Type Panel Mount
  • Rated Input Power 10 W
  • Resonant Frequency 90 Hz
  • SPL at 10cm 102 dB
  • Impedance 8 Ohm
  • Frequency Range Min 90.00 Hz
  • Frequency Range Max 15000.00 Hz
