AS06008PS-R

Description
  • Unique flat panel speaker design for ultra-wide dispersion
  • Slim 26.5mm profile for great SPL in tight mounting locations
  • High-power motor design with Neodymium magnet
Dimensions
  • Units: mm
  • Length: 66.80
  • Width: 66.80
  • Height: 26.50
  • Shape: Square
Features
  • Wide-band frequency response is great for voice and music
Electrical Specifications
  • Device Type Speaker
  • Technology Electro-Mechanical
  • Mount Type Flange
  • Rated Input Power 10 W
  • Resonant Frequency 160 Hz
  • SPL at 10cm 99 dB
  • Impedance 8 Ohm
  • Frequency Range Min 160.00 Hz
  • Frequency Range Max 18000.00 Hz
