AS01808MS-SC18-WP-R

AS01808MS-SC18-WP-R

Check Distributor Availability
Description
  • Dustproof and waterproof IP67-rated face
  • 88 dB output (2V @ 10cm)
  • Only 2.5 mm thick
Dimensions
  • Units: mm
  • Length: 18.00
  • Width: 13.00
  • Height: 2.50
  • Shape: Square
Features
  • High fidelity audio reproduction in the thinnest size possible
Electrical Specifications
  • Device Type Speaker
  • Technology Electro-Mechanical
  • Mount Type Spring Contact
  • Rated Input Power 0.5 W
  • Resonant Frequency 850 Hz
  • SPL at 10cm 88 dB
  • Impedance 8 Ohm
  • Frequency Range Min 500.00 Hz
  • Frequency Range Max 20000.00 Hz
