AS01506MS-SC15-WP-R

Description
  • PEEK diaphragm for flat frequency response
  • 93 dB output (2.45V @ 10cm)
  • High-energy neodymium motor
Dimensions
  • Units: mm
  • Length: 15.00
  • Width: 11.00
  • Height: 2.50
  • Shape: Square
Features
  • Only 2.5 mm thick with spring-loaded contacts
Electrical Specifications
  • Device Type Speaker
  • Technology Electro-Mechanical
  • Mount Type Spring Contact
  • Rated Input Power 1 W
  • Resonant Frequency 650 Hz
  • SPL at 10cm 93 dB
  • Impedance 6 Ohm
  • Frequency Range Min 650.00 Hz
  • Frequency Range Max 20000.00 Hz
