AR01232MS-SC12-WP-R

Description
  • Only 2 mm thick
  • Dustproof and waterproof IP67-rated face
  • High fidelity audio reproduction in near-phone and headphone applications
Dimensions
  • Units: mm
  • Length: 12.00
  • Width: 6.00
  • Height: 2.00
  • Shape: Square
Features
  • Custom-molded poly cone designed for voice articulation
Electrical Specifications
  • Device Type Receiver
  • Technology Electro-Mechanical
  • Mount Type Spring Contact
  • Rated Input Power 0.02 W
  • Resonant Frequency 450 Hz
  • SPL at 10cm 117 dB @ 1cm
  • Impedance 32 Ohm
  • Frequency Range Min 300.00 Hz
  • Frequency Range Max 7000.00 Hz
